17 inch LCD Screen G170HAN01.0 Square screen 1920x1920
17 inch LCD Screen G170HAN01.0 Square screen 1920x1920
17 inch LCD Screen G170HAN01.0 Square screen 1920x1920
17 inch LCD Screen G170HAN01.0 Square screen 1920x1920
17 inch LCD Screen G170HAN01.0 Square screen 1920x1920
17 inch LCD Screen G170HAN01.0 Square screen 1920x1920
17 inch LCD Screen G170HAN01.0 Square screen 1920x1920
17 inch LCD Screen G170HAN01.0 Square screen 1920x1920
17 inch LCD Screen G170HAN01.0 Square screen 1920x1920
17 inch LCD Screen G170HAN01.0 Square screen 1920x1920
17 inch LCD Screen G170HAN01.0 Square screen 1920x1920
17 inch LCD Screen G170HAN01.0 Square screen 1920x1920

17 inch LCD Screen G170HAN01.0 Square screen 1920x1920

Get a Quote
Product Description
Product Picture
17 inch LCD Screen G170HAN01.0 Square screen 1920x1920
product 17 inch lcd screen g170han010 square screen 1920x1920-1
product 17 inch lcd screen g170han010 square screen 1920x1920-2
product 17 inch lcd screen g170han010 square screen 1920x1920-3
Product Description
The description of LCD screen
Brand
LG
Model
G170HAN01.0
Diagonal Size
17 inch
Type
LCM, a-Si TFT-LCD
Pixel Format
1920(RGB)×1920
Configuration
RGB Vertical Stripe
Lamp Type
Flat Rectangle
Outline Dim.
325.01(W)×319.33(H)×12.2(D) mm
Luminance
420 cd/m² (Typ.)
Contrast Ratio
1000:1 (Typ.) (TM)
View Direction
Symmetry
Response Time
8 (Typ.)(G to G)
Viewing Angle
89/89/89/89 (Typ.)(CR≥10)
Operating Mode
ADS, Normally Black, Transmissive
Aspect Ratio
1:1(W:H)
Surface Treatment
Antiglare (Haze 25%), Hard coating (3H)
Interface Type
EDP
Power Supply
5.0V (Typ.)
Environment
Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C
The description of the board
Model No.
9514
Brightness Control
DC & PWM
Signal Interface
EDP interface
Outline Dimention
118(L)×75(W)
Temperature
0℃ To +60℃
Power for Board
12V
Details Images
product 17 inch lcd screen g170han010 square screen 1920x1920-4
product 17 inch lcd screen g170han010 square screen 1920x1920-5
product 17 inch lcd screen g170han010 square screen 1920x1920-6
product 17 inch lcd screen g170han010 square screen 1920x1920-7
product 17 inch lcd screen g170han010 square screen 1920x1920-8
product 17 inch lcd screen g170han010 square screen 1920x1920-9
Product Usage
product 17 inch lcd screen g170han010 square screen 1920x1920-10
