23.6 Inch Round Lcd Screen 1280*1280 Highlight 1500 Nits with 10 Points Touch Panel and Android Board Support WI-FI
23.6 Inch Round Lcd Screen 1280*1280 Highlight 1500 Nits with 10 Points Touch Panel and Android Board Support WI-FI
23.6 Inch Round Lcd Screen 1280*1280 Highlight 1500 Nits with 10 Points Touch Panel and Android Board Support WI-FI
23.6 Inch Round Lcd Screen 1280*1280 Highlight 1500 Nits with 10 Points Touch Panel and Android Board Support WI-FI
23.6 Inch Round Lcd Screen 1280*1280 Highlight 1500 Nits with 10 Points Touch Panel and Android Board Support WI-FI
23.6 Inch Round Lcd Screen 1280*1280 Highlight 1500 Nits with 10 Points Touch Panel and Android Board Support WI-FI
23.6 Inch Round Lcd Screen 1280*1280 Highlight 1500 Nits with 10 Points Touch Panel and Android Board Support WI-FI
23.6 Inch Round Lcd Screen 1280*1280 Highlight 1500 Nits with 10 Points Touch Panel and Android Board Support WI-FI
23.6 Inch Round Lcd Screen 1280*1280 Highlight 1500 Nits with 10 Points Touch Panel and Android Board Support WI-FI
23.6 Inch Round Lcd Screen 1280*1280 Highlight 1500 Nits with 10 Points Touch Panel and Android Board Support WI-FI
23.6 Inch Round Lcd Screen 1280*1280 Highlight 1500 Nits with 10 Points Touch Panel and Android Board Support WI-FI
23.6 Inch Round Lcd Screen 1280*1280 Highlight 1500 Nits with 10 Points Touch Panel and Android Board Support WI-FI

23.6 Inch Round Lcd Screen 1280*1280 Highlight 1500 Nits with 10 Points Touch Panel and Android Board Support WI-FI

Get a Quote
Product Description
Product Description
product 236 inch round lcd screen 12801280 highlight 1500 nits with 10 points touch panel and android board support wi fi-1
product 236 inch round lcd screen 12801280 highlight 1500 nits with 10 points touch panel and android board support wi fi-2
product 236 inch round lcd screen 12801280 highlight 1500 nits with 10 points touch panel and android board support wi fi-3
product 236 inch round lcd screen 12801280 highlight 1500 nits with 10 points touch panel and android board support wi fi-4
product 236 inch round lcd screen 12801280 highlight 1500 nits with 10 points touch panel and android board support wi fi-5
product 236 inch round lcd screen 12801280 highlight 1500 nits with 10 points touch panel and android board support wi fi-6
Products Description
23.6 inch round lcd screen 1280*1280 Highlight 1500 nits with 10 points touch panel and Android board support WI-FI
Brand
AUO
Model
DV236FBM-N00
Diagonal Size
23.6 inch
Type
a-Si TFT-LCD , LCM
Pixel Format
1280(RGB)×1280
Configuration
RGB Vertical Stripe
Active Area
599.424(W)×599.424(H) mm
Outline Dim
657(W)×657(H)×29.15(D) mm
Bezel Area
603.42(W)×603.42(H) mm
Treatment
Antiglare (Haze 2%)
Luminance
1500 cd/m² (Typ.)
Contrast Ratio
-----
View Direction
Symmetry
Response Time
----
Viewing Angle
89/89/89/89 (Typ.)(CR≥10)
Operating
Normally Black, Transmissive
Support Color
16.7M 72% NTSC
Light Source
WLED , 50K hours
Frame Rate
60Hz
Touch Panel
Without
Interface Type
LVDS (1 ch, 8-bit)
Power Supply
---
Environment
Operating Temperature: 0 ~ 50 °C -
Details Images
product 236 inch round lcd screen 12801280 highlight 1500 nits with 10 points touch panel and android board support wi fi-7
product 236 inch round lcd screen 12801280 highlight 1500 nits with 10 points touch panel and android board support wi fi-8
product 236 inch round lcd screen 12801280 highlight 1500 nits with 10 points touch panel and android board support wi fi-9
Application
product 236 inch round lcd screen 12801280 highlight 1500 nits with 10 points touch panel and android board support wi fi-10
product 236 inch round lcd screen 12801280 highlight 1500 nits with 10 points touch panel and android board support wi fi-11
product 236 inch round lcd screen 12801280 highlight 1500 nits with 10 points touch panel and android board support wi fi-12
Product Usage
product 236 inch round lcd screen 12801280 highlight 1500 nits with 10 points touch panel and android board support wi fi-13
product 236 inch round lcd screen 12801280 highlight 1500 nits with 10 points touch panel and android board support wi fi-14
product 236 inch round lcd screen 12801280 highlight 1500 nits with 10 points touch panel and android board support wi fi-15
product 236 inch round lcd screen 12801280 highlight 1500 nits with 10 points touch panel and android board support wi fi-16
product 236 inch round lcd screen 12801280 highlight 1500 nits with 10 points touch panel and android board support wi fi-17
product 236 inch round lcd screen 12801280 highlight 1500 nits with 10 points touch panel and android board support wi fi-18
product 236 inch round lcd screen 12801280 highlight 1500 nits with 10 points touch panel and android board support wi fi-19
product 236 inch round lcd screen 12801280 highlight 1500 nits with 10 points touch panel and android board support wi fi-20
Related Products
Packing&Shipping

1.About the test
product 236 inch round lcd screen 12801280 highlight 1500 nits with 10 points touch panel and android board support wi fi-21
product 236 inch round lcd screen 12801280 highlight 1500 nits with 10 points touch panel and android board support wi fi-22
2.About the Packing
EPE with Carton with Carton & Plywood case EPE with Carton&Pallet
product 236 inch round lcd screen 12801280 highlight 1500 nits with 10 points touch panel and android board support wi fi-23
product 236 inch round lcd screen 12801280 highlight 1500 nits with 10 points touch panel and android board support wi fi-24
product 236 inch round lcd screen 12801280 highlight 1500 nits with 10 points touch panel and android board support wi fi-25
product 236 inch round lcd screen 12801280 highlight 1500 nits with 10 points touch panel and android board support wi fi-26
product 236 inch round lcd screen 12801280 highlight 1500 nits with 10 points touch panel and android board support wi fi-27
product 236 inch round lcd screen 12801280 highlight 1500 nits with 10 points touch panel and android board support wi fi-28
product 236 inch round lcd screen 12801280 highlight 1500 nits with 10 points touch panel and android board support wi fi-29
3.About the Shipping
product 236 inch round lcd screen 12801280 highlight 1500 nits with 10 points touch panel and android board support wi fi-30
Company Introduction
Shenzhen Caison Technology co., LTD. Is a professional LCD module solution provider.Our product include:
Transparent OLED display（30 inch/49 inch/55 inch）
Round LCD display
Square LCD display
stretched Bar LCD display
LCD advertising machine (4.3 inch -110 inch )
LCD/LED panel(4.3 inch -110 inch );
High brightness panel(1000 -7000 brightness)
LCD kits(1080P-8K LCD controller board,Android board/Media player board, LVDS cable ,Inverter board, OSD board,Remote controll ,
Power supply,Power adapter);
Touch panel(Resistive touchscreen,IR touchscreen,Capacitance touchscreen);

We accept all kinds of customized products, including LCD screen, cable, many kind of the board (1080P-5K LCD controller
board,Android board/Media player board),Shell.....All products can be printed with your logo.
We can also apply for certificates for customers' products.Such CE ,SASO, KC, BIS, PSE and CE, FCC, RoHS to UL.....

Welcome you esteemed partners to visit us and start business on mutual benefits together. Thanks!
product 236 inch round lcd screen 12801280 highlight 1500 nits with 10 points touch panel and android board support wi fi-31
product 236 inch round lcd screen 12801280 highlight 1500 nits with 10 points touch panel and android board support wi fi-32
product 236 inch round lcd screen 12801280 highlight 1500 nits with 10 points touch panel and android board support wi fi-33
product 236 inch round lcd screen 12801280 highlight 1500 nits with 10 points touch panel and android board support wi fi-34
product 236 inch round lcd screen 12801280 highlight 1500 nits with 10 points touch panel and android board support wi fi-35
product 236 inch round lcd screen 12801280 highlight 1500 nits with 10 points touch panel and android board support wi fi-36
product 236 inch round lcd screen 12801280 highlight 1500 nits with 10 points touch panel and android board support wi fi-37
product 236 inch round lcd screen 12801280 highlight 1500 nits with 10 points touch panel and android board support wi fi-38
product 236 inch round lcd screen 12801280 highlight 1500 nits with 10 points touch panel and android board support wi fi-39
product 236 inch round lcd screen 12801280 highlight 1500 nits with 10 points touch panel and android board support wi fi-40
product 236 inch round lcd screen 12801280 highlight 1500 nits with 10 points touch panel and android board support wi fi-41
FAQ
1. Are you a factory or a trading company?
A: We are an OEM / ODM factory.
2. Can I customize the product? and can I add logo to the products?
A: We can customize any products according to any requirements of customers, such as motherboard, cable, shell .... We can also
add your logo to the product.
3. What is the warranty period of the product?
A: According to different products, our warranty time is 1 - 3 years.
4. Why choose your company?
A: We are Alibaba's 5-year faithful member, and the transaction score is always full score.
We are a factory, with certain price advantage and professional and fast technical service support.
We can also apply for certificates for customers' products.Such CE ,SASO, KC, BIS, PSE and CE, FCC, RoHS to UL.....
5. What method of payment is accepted?
A: We accept most payment methods, but mainly wire transfer, letter of credit, Western Union, paypal and MoneyGram.
6. What is the delivery time and mode of transportation?
If it is not a customized product, the sample and small orders are 1-3 days,
And the order quantity meets more than 2000 sets, which takes 5-15 days.
There are DHL, UPS, TNT and FedEx for fast transportation.
Slow and cheap modes of transportation include sea transportation, EMS, and postal parcels.
