AUO 55 Inch Splicing Digital Signage LCD Panel P550HVN08.2 With1920(RGB)*1080 700 Nits Video Wall LCD Outdoor Digital Screens

Product Description

product auo 55 inch splicing digital signage lcd panel p550hvn082 with1920rgb1080 700 nits video wall lcd outdoor digital screens-1

product auo 55 inch splicing digital signage lcd panel p550hvn082 with1920rgb1080 700 nits video wall lcd outdoor digital screens-2

product auo 55 inch splicing digital signage lcd panel p550hvn082 with1920rgb1080 700 nits video wall lcd outdoor digital screens-3

product auo 55 inch splicing digital signage lcd panel p550hvn082 with1920rgb1080 700 nits video wall lcd outdoor digital screens-4

AUO 55 inch Splicing Digital signage LCD panel P550HVN08.2 with1920(RGB)*1080 700 nits video wall LCD outdoor digital screens

AUO 55 inch high brightness LCD panel P550HVN08.2 support 1920(RGB)*1080 700 nits High brightness LCD screen 55" diagonal a-Si TFT-LCD display panel sRGB Landscape / Portrait Hight AUO 55 inch Splicing Digital signage LCD panel P550HVN08.2 with1920(RGB)*1080 700 nits video wall LCD advertising display screen Splicing LCD panel P550HVN08.2 outdoor digital screens

Support for HDMI input and Android. We support for all colors of the entire shell customization. We support for a variety of certification.

Model P/N	P550HVN08.2	Brand	AUO
Active area	1209.6(W)×680.4(H) mm	Resolution	1920(RGB)×1080, FHD 40PPI
Outline (mm)	1211.8(W)×682.6(H)×49.2(D) mm	Bezel Opening	1210.0(W)×680.8(H) mm
Treatment	Antiglare (Haze 44%), Hard coating (3H)	Color Depth	16.7M 99% sRGB
Viewing angle	89/89/89/89 (Typ.)(CR≥10)	Diagonal Size	55 inch
Display mode	AMVA3, Normally Black, Transmissive	Interface Type	LVDS (2 ch, 8-bit) 51 pins Connector
Contrast ratio	4000:1 (Typ.) (TM)	Power Supply	12.0V (Typ.)
Luminance	700 cd/m² (Typ.)	Response Time	8 (Typ.)(G to G)
Environment	Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C

Details Images

product auo 55 inch splicing digital signage lcd panel p550hvn082 with1920rgb1080 700 nits video wall lcd outdoor digital screens-7

55 inch high brightness display with 1000-5000 high brightness.

product auo 55 inch splicing digital signage lcd panel p550hvn082 with1920rgb1080 700 nits video wall lcd outdoor digital screens-8

product auo 55 inch splicing digital signage lcd panel p550hvn082 with1920rgb1080 700 nits video wall lcd outdoor digital screens-9

Brightness Test

Enlarged close-up of the luminometer

Product Usage

product auo 55 inch splicing digital signage lcd panel p550hvn082 with1920rgb1080 700 nits video wall lcd outdoor digital screens-10

product auo 55 inch splicing digital signage lcd panel p550hvn082 with1920rgb1080 700 nits video wall lcd outdoor digital screens-11

product auo 55 inch splicing digital signage lcd panel p550hvn082 with1920rgb1080 700 nits video wall lcd outdoor digital screens-12

product auo 55 inch splicing digital signage lcd panel p550hvn082 with1920rgb1080 700 nits video wall lcd outdoor digital screens-13

product auo 55 inch splicing digital signage lcd panel p550hvn082 with1920rgb1080 700 nits video wall lcd outdoor digital screens-14

product auo 55 inch splicing digital signage lcd panel p550hvn082 with1920rgb1080 700 nits video wall lcd outdoor digital screens-15

product auo 55 inch splicing digital signage lcd panel p550hvn082 with1920rgb1080 700 nits video wall lcd outdoor digital screens-16

product auo 55 inch splicing digital signage lcd panel p550hvn082 with1920rgb1080 700 nits video wall lcd outdoor digital screens-17

Related Products

Packing&Shipping

1.About the test

product auo 55 inch splicing digital signage lcd panel p550hvn082 with1920rgb1080 700 nits video wall lcd outdoor digital screens-18

product auo 55 inch splicing digital signage lcd panel p550hvn082 with1920rgb1080 700 nits video wall lcd outdoor digital screens-19

2.About the Packing

EPE with Carton with Carton & Plywood case EPE with Carton&Pallet

product auo 55 inch splicing digital signage lcd panel p550hvn082 with1920rgb1080 700 nits video wall lcd outdoor digital screens-20

product auo 55 inch splicing digital signage lcd panel p550hvn082 with1920rgb1080 700 nits video wall lcd outdoor digital screens-21

product auo 55 inch splicing digital signage lcd panel p550hvn082 with1920rgb1080 700 nits video wall lcd outdoor digital screens-22

product auo 55 inch splicing digital signage lcd panel p550hvn082 with1920rgb1080 700 nits video wall lcd outdoor digital screens-23

product auo 55 inch splicing digital signage lcd panel p550hvn082 with1920rgb1080 700 nits video wall lcd outdoor digital screens-24

product auo 55 inch splicing digital signage lcd panel p550hvn082 with1920rgb1080 700 nits video wall lcd outdoor digital screens-25

product auo 55 inch splicing digital signage lcd panel p550hvn082 with1920rgb1080 700 nits video wall lcd outdoor digital screens-26

3.About the Shipping

product auo 55 inch splicing digital signage lcd panel p550hvn082 with1920rgb1080 700 nits video wall lcd outdoor digital screens-27

Company Introduction

Shenzhen Caison Technology co., LTD. Is a professional LCD module solution provider.Our product include:
LCD/LED panel(4.3 inch -110 inch );
LCD kits(1080P-5K LCD controller board,Android board/Media player board, LVDS cable ,Inverter board, OSD board,Remote controll ,
Power supply,Power adapter);
Touch panel(Resistive touchscreen,IR touchscreen,Capacitance touchscreen);
High brightness panel;
We accept all kinds of customized products, including LCD screen, cable, many kind of the board (1080P-5K LCD controller
board,Android board/Media player board),Shell.....All products can be printed with your logo.
We can also apply for certificates for customers' products.Such CE ,SASO, KC, BIS, PSE and CE, FCC, RoHS to UL.....

Welcome you esteemed partners to visit us and start business on mutual benefits together. Thanks!

product auo 55 inch splicing digital signage lcd panel p550hvn082 with1920rgb1080 700 nits video wall lcd outdoor digital screens-28

product auo 55 inch splicing digital signage lcd panel p550hvn082 with1920rgb1080 700 nits video wall lcd outdoor digital screens-29

product auo 55 inch splicing digital signage lcd panel p550hvn082 with1920rgb1080 700 nits video wall lcd outdoor digital screens-30

product auo 55 inch splicing digital signage lcd panel p550hvn082 with1920rgb1080 700 nits video wall lcd outdoor digital screens-31

product auo 55 inch splicing digital signage lcd panel p550hvn082 with1920rgb1080 700 nits video wall lcd outdoor digital screens-32

product auo 55 inch splicing digital signage lcd panel p550hvn082 with1920rgb1080 700 nits video wall lcd outdoor digital screens-33

product auo 55 inch splicing digital signage lcd panel p550hvn082 with1920rgb1080 700 nits video wall lcd outdoor digital screens-34

product auo 55 inch splicing digital signage lcd panel p550hvn082 with1920rgb1080 700 nits video wall lcd outdoor digital screens-35

product auo 55 inch splicing digital signage lcd panel p550hvn082 with1920rgb1080 700 nits video wall lcd outdoor digital screens-36

product auo 55 inch splicing digital signage lcd panel p550hvn082 with1920rgb1080 700 nits video wall lcd outdoor digital screens-37

product auo 55 inch splicing digital signage lcd panel p550hvn082 with1920rgb1080 700 nits video wall lcd outdoor digital screens-38

FAQ

1. Are you a factory or a trading company?
A: We are an OEM / ODM factory.
2. Can I customize the product? and can I add logo to the products?
A: We can customize any products according to any requirements of customers, such as motherboard, cable, shell .... We can also
add your logo to the product.
3. What is the warranty period of the product?
A: According to different products, our warranty time is 1 - 3 years.
4. Why choose your company?
A: We are Alibaba's 5-year faithful member, and the transaction score is always full score.
We are a factory, with certain price advantage and professional and fast technical service support.
We can also apply for certificates for customers' products.Such CE ,SASO, KC, BIS, PSE and CE, FCC, RoHS to UL.....
5. What method of payment is accepted?
A: We accept most payment methods, but mainly wire transfer, letter of credit, Western Union, paypal and MoneyGram.
6. What is the delivery time and mode of transportation?
If it is not a customized product, the sample and small orders are 1-3 days,
And the order quantity meets more than 2000 sets, which takes 5-15 days.
There are DHL, UPS, TNT and FedEx for fast transportation.
Slow and cheap modes of transportation include sea transportation, EMS, and postal parcels.
