B0E 18.5 inch digital signage and display resolution 1366x768 Brightness 250 cd/m2 LCD Panel DV185WHM-NM1

Product Description
B0E 18.5 inch digital signage and display resolution 1366x768 Brightness 250 cd/m2 LCD Panel DV185WHM-NM1
Product Description
Details Images
m2 lcd panel dv185whm nm1-1
m2 lcd panel dv185whm nm1-2
m2 lcd panel dv185whm nm1-3
m2 lcd panel dv185whm nm1-4
2.Specification LCD panel
Panel Brand
BOE
Panel Model
DV185WHM-NM1
Panel Size
18.5 inch
Panel Type
a-Si TFT-LCD, LCM
Resolution
1366(RGB)×768, WXGA 84PPI
Pixel Format
RGB Vertical Stripe
Active Area
409.8(W)×230.4(H) mm
Outline Dim
430.4 × 254.6 × 11.4 (H×V×D)
Brightness
250 cd/m² (Typ.)
Contrast Ratio
1000:1 (Typ.) (TM)
Viewing Angle
89/89/89/89 (Typ.)(CR≥10)
Display Mode
8(Typ.)(G to G)
Interface Type
LVDS (1 ch, 8-bit) , 30 pins Connector
Power Supply
5V
Environment
Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
