Home > Products > Digital signage > Wheeled mobile advertising machine
Panel size: |
43 inches |
Resolution |
1920*1080 |
Aspect ratio: |
16:9 |
brightness: |
1500 |
Contrast |
4000:1 |
Perspective: |
178°/178° |
Warranty: |
1 year |
Brand |
Innolux |
Model |
CS430-A02 |
||
Diagonal Size |
43inch |
Type |
a-Si TFT-LCD, LCM |
||
Resolution |
1920(LCR)×1080, QSXGA 153PPI |
Pixel Format |
LCR Vertical Stripe |
||
Active Area |
422.4(W)×337.92(H) mm |
Bezel Opening |
426.4(W)×344.5(H) mm |
||
Outline Size |
459.8(W)×375.3(H)×30.5(D) mm |
Treatment |
Antiglare |
||
Brightness |
1500 cd/m² (Typ.) |
Contrast Ratio |
1200:1 (Typ.) (TM) |
||
Best view on |
Symmrtry |
Response Time |
15/10 (Typ.)(Tr/Td) |
||
Viewing Angle |
85/85/85/85 (Typ.)(CR≥20) |
Operating Mode |
DD-IPS, Normally Black, Transmissive |
||
Display Color |
Grayscale |
Lamp Type |
WLED , 50K hours , With LED Driver |
||
Frame Rate |
60Hz |
Touch Panel |
Without |
||
Interface Type |
LVDS (4 ch, 10-bit) 90 pins Connector |
Power Supply |
12.0V (Typ.) |
||
Environment |
Storage Temp.: -20 ~ 60 °C ;Operating Temp.: 0 ~ 50 °C |
||||
