Panel |
S320HJJ-T03 |
Brand |
Innolux |
||
Resolution |
1920(RGB)×1080, FHD, 69PPI |
Diagonal Size |
32 inch |
||
Active area |
698.4(W)×392.85(H) mm |
Response Time |
9.5 (Typ.)(G to G) ms |
||
Viewing angle |
89/89/89/89 (Typ.)(CR≥10) |
Interface Type |
LVDS (2 ch, 8-bit) , 51 pins Connector |
||
Display mode |
Super MVA, Normally Black, Transmissive |
Power Supply |
12.0V (Typ.) |
||
Contrast ratio |
5000:1 (Typ.) (TM) |
Luminance |
2000cd/m² (Typ.) |
||
Environment |
Operating Temperature: -30~ 70 °C ; Storage Temperature: -30 ~ 70 °C |
