P320HVN07.1 32 Inch High Brightness LCD Module 2500nits LCD Screen 1920*1080 Outdoor Digital Signage

Product Description
Product Description
product p320hvn071  32 inch high brightness lcd module 2500nits lcd screen 19201080 outdoor digital signage-1
product p320hvn071  32 inch high brightness lcd module 2500nits lcd screen 19201080 outdoor digital signage-2
product p320hvn071  32 inch high brightness lcd module 2500nits lcd screen 19201080 outdoor digital signage-3
product p320hvn071  32 inch high brightness lcd module 2500nits lcd screen 19201080 outdoor digital signage-4
product p320hvn071  32 inch high brightness lcd module 2500nits lcd screen 19201080 outdoor digital signage-5
product p320hvn071  32 inch high brightness lcd module 2500nits lcd screen 19201080 outdoor digital signage-6
P320HVN07.1 32 Inch High Brightness LCD Module 2500nits LCD Screen 1920*1080 Outdoor Digital Signage.

Outdoor digital signage,lcd panel.

Resolution 1920 x 1080, Support for HDMI input and Android. We support for all colors of the entire shell customization. We support for a variety of certification.
Brand
AUO
Model
P320HVN07.1
Diagonal Size
32 inch
Type
a-Si TFT-LCD, LCM
Pixel Format
RGB Vertical Stripe
Resolution
1920(RGB)×1080, FHD 69PPI
Active Area
698.4(W)×392.85(H) mm
Outline Dim.
721.2(W)×415.65(H) ×58.5(D) mm
Power Supply
12.0V (Typ.)
Surface
Antiglare (Haze 28%), Hard coating (3H)
Luminance
2500 cd/m² (Typ.)
Contrast Ratio
4000 : 1 (Typ.) (TM)
View Direction
Symmetry
Response Time
8 (Typ.)(G to G)
Viewing Angle
89/89/89/89 (Typ.)(CR≥10)
Work Mode
AMVA3, Normally Black, Transmissive
Support Color
16.7M 72% sRGB
Light Source
WLED , 50K hours , With LED Driver
Frame Rate
60Hz
Touch Panel
Without
Interface Type
* LVDS (2 ch, 8-bit) , 51 pins Connector
Environment
Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -20 ~ 60 °C
Details Images
product p320hvn071  32 inch high brightness lcd module 2500nits lcd screen 19201080 outdoor digital signage-7
P320HVN07.1 32 Inch High Brightness LCD Module 2500nits LCD Screen 1920*1080 Outdoor Digital Signage..
product p320hvn071  32 inch high brightness lcd module 2500nits lcd screen 19201080 outdoor digital signage-8
product p320hvn071  32 inch high brightness lcd module 2500nits lcd screen 19201080 outdoor digital signage-9
Brightness Test
Enlarged close-up of the luminometer
Product Usage
product p320hvn071  32 inch high brightness lcd module 2500nits lcd screen 19201080 outdoor digital signage-10
product p320hvn071  32 inch high brightness lcd module 2500nits lcd screen 19201080 outdoor digital signage-11
product p320hvn071  32 inch high brightness lcd module 2500nits lcd screen 19201080 outdoor digital signage-12
product p320hvn071  32 inch high brightness lcd module 2500nits lcd screen 19201080 outdoor digital signage-13
product p320hvn071  32 inch high brightness lcd module 2500nits lcd screen 19201080 outdoor digital signage-14
product p320hvn071  32 inch high brightness lcd module 2500nits lcd screen 19201080 outdoor digital signage-15
product p320hvn071  32 inch high brightness lcd module 2500nits lcd screen 19201080 outdoor digital signage-16
product p320hvn071  32 inch high brightness lcd module 2500nits lcd screen 19201080 outdoor digital signage-17
