Brand |
SAMSUNG |
Model |
LTI550HN17 |
||
Diagonal Size |
55 inch |
Type |
LCM , a-Si TFT-LCD |
||
Pixel Format |
1920(RGB)×1080 [FHD] 40PPI |
Configuration |
RGB Vertical Stripe |
||
Active Area |
1209.6(H)×680.4(V) mm |
Outline Dim. |
1209.8(W)×680.6(H) mm |
||
Bezel Area |
1213.5(W)×684.3(H) ×67.7(D) mm |
Treatment |
Antiglare (Haze 44%), Hard coating (3H) |
||
Luminance |
500 cd/m² (Typ.) |
Contrast Ratio |
4000 : 1 (Typ.) (TM) |
||
View Direction |
Symmetry |
Response Time |
8 (Typ.)(G to G) |
||
Viewing Angle |
89/89/89/89 (Typ.)(CR≥10) |
Operating Mode |
SVA, Normally Black, Transmissive |
||
Support Color |
16.7M 100% sRGB |
Light Source |
WLED , 50K hours , With LED Driver |
||
Frame Rate |
60Hz |
Touch Panel |
Without |
||
Interface Type |
LVDS (2 ch, 8-bit) , 51 pins Connector |
Power Supply |
12.0V (Typ.) |
||
Environment |
Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 65 °C |
||||
